R8184G4009 Resideo Protectorelay Oil Burner Control

Protectorelay Oil Burner Control, Controls Oil Burner, Oil Valve and the Ignition Transformer in Response to a Call for Heat, 45 Second Safety Switch Timing, With LED for Lockout Indication and Manual Trip Lever on Safety Switch to Assure Shutdown during servicing, Full Load Contact Ratings: 7.4 Amp @ 120Vac, 3.7 Amp @ 240Vac, Locked Rotor Contact Ratings: 44.4 Amp @ 120Vac, 22.2 Amp @ 240Vac, Pilot Duty Alarm Load Ratings: 75Va @ 120/240Vac, 25Va @ 24Vac, Resistive Alarm Load Ratings: 1.5 Amp @ 120/240Vac, 3 Amp @ 24Vac, -40-130 Degree Temperature Range.

Replaces R8184G 1427, ICM1503

OIL BURNER CONTROL

R8184G4009 CAD CELL RELAY (45 SEC)INTERMITTENT,120V COO=USA

Part Description:
  • Oil Burner Control
  • Flame Establishing Period 45 Second
  • Pilot Type Intermittent
  • Voltage Rating 120/240 Volt AC at 50/60 Hertz
  • Operating Temperature -40 to 130 Deg F
  • Size 4-1/8 Inch Width x 2-1/2 Inch Depth x 4-3/8 Inch Height
  • Application Oil Burner System
  • Approval UL, CSA
  • Current Rating 7.4 Amp at 120 Volt AC/3.7 Amp at 240 Volt AC (Full Load), 44.4 Amp at 120 Volt AC, 22.2 Amp at 240 Volt AC (Locked Rotor)
  • Mounting 4 Inch x 4 Inch Standard Junction Box/Direct Mount

UPC:  08526707862

Part Number: R8184G4009/U

FEATURES / BENEFITS

  • Oil Burner Control Provides Automatic, Non-Recycling Control of an Intermittent Ignition Oil Burner System
  • Controls Oil Burner, Oil Valve (If Desired) and the Ignition Transformer in Response to a Call for Heat
  • Solid State Flame Sensing Circuit
  • LED on Terminal Strip Indicates System Lockout
  • Remote Lockout Indication
  • Enclosed Safety Switch with External Reset Button
  • Manual Trip Lever Opens Safety Switch for System Maintenance

SPECIFICATIONS

MANUFACTURER  HONEYWELL RESIDENTIAL
MANUFACTURER PART NUMBER  R8184G4009/U
METROPAC INTERNAL PART NUMBER  2614
ADDITIONAL INFORMATION  Current Rating 7.4 Amp at 120 Volt AC/3.7 Amp at 240 Volt AC (Full Load), 44.4 Amp at 120 Volt AC, 22.2 Amp at 240 Volt AC (Locked Rotor); Mounting 4 Inch x 4 Inch Standard Junction Box/Direct Mount
PRODUCT NAME  Oil Burner Control
UPC CODE  08526707862
